Cellular Rural Small Static Scenarios (35001-35005)

Overview

Label

Value

Version

Formal

RF ID

35001, 35002, 35003, 35004, 35005

RF Description

35001 (Cellular Rural Small 1 GHz Static 1 + 40 dB) 35002 (Cellular Rural Small 3.6 GHz Static 1 + 51 dB) 35003 (Cellular Rural Small 3.6 GHz Static 1 + 40 dB) 35004 (Cellular Rural Small 3.6 GHz Static 1 at 3.6 GHz + 51 dB) 35005 (Cellular Rural Small 3.6 GHz Static 1 at 3.6 GHz + 40 dB)

Noise power BW (MHz)

20

Usable BW for transmissions (MHz)

80

Traffic ID

N/A

Traffic Description

N/A

Center Frequency

1 GHz (35001, 35002, 35003) 3.6 GHz (35004, 35005)

Number of Nodes

13

Duration

1 second

Narrative

This set of scenarios aims at replicating a generic rural environment with one center node (e.g., a Base Station (BS)) and 12 others (e.g., User Equipments (UE)) randomly scattered around. The channel has been created via a mathematical model at two center frequencies: 1 GHz and 3.6 GHz. Only the links between the BS and the UEs (and vice-versa) have been defined, all others are set to 0.

Node Placement

The BS is located in the center of a 20x20 meters area, with the UEs randomly scattered around. The height of the nodes is:

  • BS-01 height: 3 meters

  • UE height: 1 meter

Cellular Rural Node Placement

Parameters

Label

Value

Title

Cellular Rural Small [1 GHz - 3.6 GHz] Static 1 [at 3.6 GHz] + [40 - 51] dB

Scenario ID

35001, 35002, 35003, 35004, 35005

Scenario Duration

1 second

Scenario Repeats at End?

True

Number of Nodes

13

Max Scenario Bandwidth

80 MHz

Node Mobility

No

Channel Simulation Frequency

1 GHz (35001) 3.6 GHz (35002, 35003, 35004, 35005)

Emulation Center Frequency

1 GHz (35001, 35002, 35003) 3.6 GHz (35004, 35005)

Channel Characteristics

The channel characteristics have been computed by following the free-space path loss formula:

\[FSPL = 20log_{10}\left(\frac{4\pi df}{c}\right)\]

Where:

  • f = center frequency, which is equal to 1 GHz (35001) or 3.6 GHz (35002, 35003, 35004, 35005)

  • c = speed of light

  • d = 3D distance BS-UE

The link is only defined between BS and UE. The link UE-UE and loopback links (BS-BS and same UE) are not defined and they are set to be empty channels with no transmission. Moreover, to compensate for the Colosseum Base Loss and to make the scenarios falling inside the Colosseum dynamic range, an increase in the path gains has been added equal for all the links: 40 dB (35001, 35003, 35005), and 51 dB (35002, 35004).
